Stainless Steel Braided Fibreglass Insulated Flat Twin (480°C)
We supply 7/0.2mm, 13/0.2mm dia stranded or 1/0.5mm dia solid cable in 25, 50, 100 or 200 metre lengths in thermocouple types KX, TX, JX, NX or RCA/SCA. Each conductor is insulated in fibreglass, the cores are laid flat, sheathed in fibreglass then overall stainless steel braided. All conductors used are made from the relevant thermocouple material and meets IEC 60584-1 Class 2 : 2013 up to 480°C.
- 7/0.2mm, 13/0.2mm dia stranded or 1/0.5mm dia solid conductors, laid flat sheathed construction, overall Stainless Steel braid
- Insulation: Fibreglass rated to 480°C
- Colour coded (colour tracer):-
Type KX: yellow outer sheath, yellow positive wire and red negative wire
Type TX: blue outer sheath, blue positive wire and red negative wire
Type JX: black outer sheath, white positive wire and red negative wire
Type NX: orange outer sheath, orange positive wire and red negative wire
Type RX/SX: green outer sheath, black positive wire and red negative wire
- Available in a variety of lengths
- Easy connection to our range of sensors via our range of connector systems or the rear terminals on our range of indicators, controllers and programmers
The following types are available:
