1.0, 1.5 and 3.0mm diameter Mineral Insulated Thermocouple with Pot Seal and Cable

1.0, 1.5 and 3.0mm diameter Mineral Insulated Thermocouple with Pot Seal and Cable view larger image
These semi rigid thermocouples are ideal for all applications from simple temperature measurement to more arduous environments. They have insulated junctions to prevent earth loops and can be formed to shape to suit particular applications without impairing performance. A pot seal which allows the transition to 1 metre PVC insulated leads is supplied as standard. A range of extension cables and adjustable compression fittings can be found in this catalogue to complement this product.
  • Thermocouple types K, T, J, N or R available
  • Variety of lengths and diameters available
  • Various sheath materials available as listed below
  • The operating range of these sensors is shown in the order code boxes
  • Insulated Junction
  • Leads: 1 metre PVC insulated colour coded to ANSI MC96.1
  • Terminated in a pot seal 6.35mm diameter x 31mm long rated to 105°C
  • The maximum operating temperature is dependant on diameter and environmental factors, further guidance is available here.
The following types are available:

Type K - 310 Stainless Steel Sheath (1100ºC)

Order Code Description 1 - 9 10 - 24 25+ Buy
608-052 1.0mm dia x 100mm long $57.00 $52.00 $47.00 Add
608-053 1.0mm dia x 150mm long $58.00 $52.00 $47.50 Add
608-054 1.0mm dia x 200mm long $59.00 $53.00 $47.90 Add
608-055 1.0mm dia x 250mm long $59.00 $53.00 $48.10 Add
608-056 1.0mm dia x 300mm long $60.00 $54.00 $48.60 Add
608-058 1.0mm dia x 400mm long $60.00 $54.00 $48.90 Add
608-059 1.0mm dia x 500mm long $60.00 $55.00 $49.30 Add
608-060 1.0mm dia x 750mm long $62.00 $56.00 $51.00 Add
608-062 1.0mm dia x 1000mm long $64.00 $58.00 $53.00 Add
608-063 1.0mm dia x 1500mm long $69.00 $63.00 $58.00 Add
608-065 1.0mm dia x 2000mm long $75.00 $68.00 $62.00 Add
608-067 1.0mm dia x 3000mm long $85.00 $78.00 $72.00 Add
605-000 1.5mm dia x 100mm long $42.00 $38.20 $35.10 Add
605-001 1.5mm dia x 150mm long $42.20 $38.60 $35.20 Add
605-002 1.5mm dia x 200mm long $42.40 $38.90 $35.50 Add
605-003 1.5mm dia x 250mm long $42.90 $39.20 $35.90 Add
605-004 1.5mm dia x 300mm long $43.10 $39.40 $36.20 Add
605-006 1.5mm dia x 400mm long $43.80 $40.00 $36.60 Add
605-007 1.5mm dia x 500mm long $44.10 $40.30 $36.80 Add
605-008 1.5mm dia x 750mm long $46.30 $42.20 $38.70 Add
605-010 1.5mm dia x 1000mm long $48.00 $43.80 $40.00 Add
605-011 1.5mm dia x 1500mm long $54.00 $48.90 $44.80 Add
605-013 1.5mm dia x 2000mm long $60.00 $55.00 $49.20 Add
605-014 1.5mm dia x 3000mm long $72.00 $65.00 $60.00 Add
605-015 3.0mm dia x 100mm long $40.80 $37.20 $34.10 Add
605-016 3.0mm dia x 150mm long $41.30 $37.60 $34.40 Add
605-017 3.0mm dia x 200mm long $41.60 $37.90 $34.80 Add
605-018 3.0mm dia x 250mm long $41.90 $38.40 $35.10 Add
605-019 3.0mm dia x 300mm long $42.30 $38.60 $35.30 Add
605-020 3.0mm dia x 400mm long $43.70 $39.90 $36.60 Add
605-022 3.0mm dia x 500mm long $45.40 $41.10 $37.60 Add
605-023 3.0mm dia x 750mm long $48.10 $43.50 $40.00 Add
605-025 3.0mm dia x 1000mm long $52.00 $46.30 $41.90 Add
605-026 3.0mm dia x 1500mm long $57.00 $52.00 $46.30 Add
605-028 3.0mm dia x 2000mm long $64.00 $57.00 $53.00 Add
605-029 3.0mm dia x 3000mm long $70.30 $65.00 $59.00 Add

Type K - Inconel 600® Sheath (1100ºC)

Order Code Description 1 - 9 10 - 24 25+ Buy
608-109 1.0mm dia x 100mm long $57.00 $52.00 $47.00 Add
608-110 1.0mm dia x 150mm long $58.00 $52.00 $47.50 Add
608-111 1.0mm dia x 200mm long $59.00 $53.00 $47.90 Add
608-112 1.0mm dia x 250mm long $59.00 $53.00 $48.10 Add
608-113 1.0mm dia x 300mm long $60.00 $54.00 $48.60 Add
608-114 1.0mm dia x 400mm long $60.00 $54.00 $48.90 Add
608-116 1.0mm dia x 500mm long $60.00 $55.00 $49.30 Add
608-117 1.0mm dia x 750mm long $62.00 $56.00 $51.00 Add
608-119 1.0mm dia x 1000mm long $64.00 $58.00 $53.00 Add
608-120 1.0mm dia x 1500mm long $69.00 $63.00 $58.00 Add
608-122 1.0mm dia x 2000mm long $75.00 $68.00 $62.00 Add
608-124 1.0mm dia x 3000mm long $85.00 $78.00 $72.00 Add
605-049 1.5mm dia x 100mm long $42.00 $38.20 $35.10 Add
605-050 1.5mm dia x 150mm long $42.20 $38.60 $35.20 Add
605-051 1.5mm dia x 200mm long $42.40 $38.90 $35.50 Add
605-052 1.5mm dia x 250mm long $42.90 $39.20 $35.90 Add
605-053 1.5mm dia x 300mm long $43.10 $39.40 $36.20 Add
605-054 1.5mm dia x 400mm long $43.80 $40.00 $36.60 Add
605-056 1.5mm dia x 500mm long $44.10 $40.30 $36.80 Add
605-057 1.5mm dia x 750mm long $46.30 $42.20 $38.70 Add
605-059 1.5mm dia x 1000mm long $48.00 $43.80 $40.00 Add
605-060 1.5mm dia x 1500mm long $54.00 $48.90 $44.80 Add
605-062 1.5mm dia x 2000mm long $61.00 $56.00 $51.00 Add
605-063 1.5mm dia x 3000mm long $72.00 $65.00 $60.00 Add
605-064 3.0mm dia x 100mm long $40.80 $37.20 $34.10 Add
605-065 3.0mm dia x 150mm long $41.30 $37.60 $34.40 Add
605-066 3.0mm dia x 200mm long $41.60 $37.90 $34.80 Add
605-067 3.0mm dia x 250mm long $41.90 $38.40 $35.10 Add
605-068 3.0mm dia x 300mm long $42.30 $38.60 $35.30 Add
605-069 3.0mm dia x 400mm long $43.70 $39.90 $36.60 Add
605-071 3.0mm dia x 500mm long $45.40 $41.10 $37.60 Add
605-072 3.0mm dia x 750mm long $48.10 $43.50 $40.00 Add
605-074 3.0mm dia x 1000mm long $52.00 $46.30 $41.90 Add
605-075 3.0mm dia x 1500mm long $57.00 $52.00 $46.30 Add
605-077 3.0mm dia x 2000mm long $64.00 $57.00 $53.00 Add
605-078 3.0mm dia x 3000mm long $70.30 $65.00 $59.00 Add

Type T - 321 Stainless Steel Sheath (400ºC)

Order Code Description 1 - 9 10 - 24 25+ Buy
608-201 1.0mm dia x 150mm long $58.00 $52.00 $47.50 Add
608-204 1.0mm dia x 300mm long $60.00 $54.00 $48.60 Add
608-207 1.0mm dia x 500mm long $60.00 $55.00 $49.30 Add
608-210 1.0mm dia x 1000mm long $64.00 $58.00 $53.00 Add
608-213 1.0mm dia x 2000mm long $75.00 $68.00 $62.00 Add
605-110 1.5mm dia x 150mm long $42.20 $38.60 $35.20 Add
605-113 1.5mm dia x 300mm long $43.10 $39.40 $36.20 Add
605-116 1.5mm dia x 500mm long $44.10 $40.30 $36.80 Add
605-119 1.5mm dia x 1000mm long $48.00 $43.80 $40.00 Add
605-122 1.5mm dia x 2000mm long $60.00 $54.00 $49.00 Add
605-125 3.0mm dia x 150mm long $46.40 $42.30 $38.70 Add
605-128 3.0mm dia x 300mm long $47.50 $43.40 $39.70 Add
605-131 3.0mm dia x 500mm long $51.00 $46.20 $42.20 Add
605-134 3.0mm dia x 1000mm long $58.00 $52.00 $47.10 Add
605-137 3.0mm dia x 2000mm long $69.00 $63.00 $58.00 Add

Type J - 321 Stainless Steel Sheath (800ºC)

Order Code Description 1 - 9 10 - 24 25+ Buy
608-250 1.0mm dia x 150mm long $58.00 $52.00 $47.50 Add
608-253 1.0mm dia x 300mm long $60.00 $54.00 $48.60 Add
608-256 1.0mm dia x 500mm long $60.00 $55.00 $49.30 Add
608-259 1.0mm dia x 1000mm long $64.00 $58.00 $53.00 Add
608-262 1.0mm dia x 2000mm long $75.00 $68.00 $62.00 Add
605-160 1.5mm dia x 150mm long $42.20 $38.60 $35.20 Add
605-163 1.5mm dia x 300mm long $43.10 $39.40 $36.20 Add
605-166 1.5mm dia x 500mm long $44.10 $40.30 $36.80 Add
605-169 1.5mm dia x 1000mm long $48.00 $43.80 $40.00 Add
605-172 1.5mm dia x 2000mm long $60.00 $55.00 $49.20 Add
605-175 3.0mm dia x 150mm long $46.40 $42.30 $38.70 Add
605-178 3.0mm dia x 300mm long $47.50 $43.40 $39.70 Add
605-181 3.0mm dia x 500mm long $51.00 $46.20 $42.20 Add
605-184 3.0mm dia x 1000mm long $58.00 $52.00 $47.10 Add
605-187 3.0mm dia x 2000mm long $69.00 $63.00 $58.00 Add

Type N - Inconel 600® Sheath (1100ºC)

Order Code Description 1 - 9 10 - 24 25+ Buy
608-916 1.0mm dia x 150mm long $53.00 $47.90 $43.90 Add
608-918 1.0mm dia x 300mm long $54.00 $48.60 $44.80 Add
608-920 1.0mm dia x 500mm long $56.00 $51.00 $46.20 Add
608-922 1.0mm dia x 1000mm long $60.00 $55.00 $49.70 Add
608-924 1.0mm dia x 2000mm long $67.00 $63.00 $58.00 Add
608-926 1.5mm dia x 150mm long $52.00 $47.50 $43.30 Add
608-928 1.5mm dia x 300mm long $53.00 $48.10 $44.10 Add
608-930 1.5mm dia x 500mm long $54.00 $48.80 $44.80 Add
608-932 1.5mm dia x 1000mm long $60.00 $53.00 $48.40 Add
608-934 1.5mm dia x 2000mm long $66.00 $61.00 $56.00 Add
608-936 3.0mm dia x 150mm long $49.70 $45.40 $41.70 Add
608-938 3.0mm dia x 300mm long $51.00 $46.60 $42.60 Add
608-940 3.0mm dia x 500mm long $52.00 $47.90 $43.70 Add
608-942 3.0mm dia x 1000mm long $57.00 $52.00 $47.00 Add
608-944 3.0mm dia x 2000mm long $69.00 $64.00 $59.00 Add

Type N - Nicrotherm DTM Sheath (1250ºC)

Order Code Description 1 - 9 10 - 24 25+ Buy
608-310 1.0mm dia x 150mm long $56.00 $51.00 $46.60 Add
608-313 1.0mm dia x 300mm long $59.00 $54.00 $49.40 Add
608-316 1.0mm dia x 500mm long $63.00 $59.00 $55.00 Add
608-319 1.0mm dia x 1000mm long $76.00 $70.00 $64.00 Add
608-322 1.0mm dia x 2000mm long $99.00 $90.00 $84.00 Add
605-210 1.5mm dia x 150mm long $57.00 $52.00 $47.40 Add
605-213 1.5mm dia x 300mm long $62.00 $57.00 $52.00 Add
605-216 1.5mm dia x 500mm long $67.00 $63.00 $59.00 Add
605-219 1.5mm dia x 1000mm long $87.00 $80.00 $75.00 Add
605-222 1.5mm dia x 2000mm long $121.00 $112.00 $103.00 Add
605-225 3.0mm dia x 150mm long $55.00 $49.90 $45.90 Add
605-228 3.0mm dia x 300mm long $61.00 $55.00 $51.00 Add
605-231 3.0mm dia x 500mm long $66.00 $61.00 $56.00 Add
605-234 3.0mm dia x 1000mm long $77.00 $71.00 $64.00 Add
605-237 3.0mm dia x 2000mm long $138.00 $128.00 $118.00 Add

Type R - Inconel 600® Sheath (850ºC)

Order Code Description 1 - 9 10 - 24 25+ Buy
608-610 1.0mm dia x 300mm long $243.00 $222.00 $204.00 Add
608-613 1.0mm dia x 500mm long $366.00 $333.00 $305.00 Add
608-616 1.0mm dia x 1000mm long $667.00 $607.00 $556.00 Add
608-619 1.5mm dia x 300mm long $243.00 $222.00 $204.00 Add
608-622 1.5mm dia x 500mm long $366.00 $333.00 $305.00 Add
608-625 1.5mm dia x 1000mm long $667.00 $607.00 $556.00 Add
