Ultra Fine Wire PFA Thermocouple (0.08mm dia)

Ultra Fine Wire PFA Thermocouple (0.08mm dia) view larger image
A very fast response PFA insulated thermocouple, made from an extremely thin yet reliable and robust cable, able to see a wide temperature range. This sensor is ideally suited to temperature monitoring where a fast response is required, as well as an application with very little space to work with. Available with or without a miniature thermocouple plug attached in 2 or 5 metre lengths. The insulation material is colour coded to IEC 60584-3.
  • Thermocouple types K & T
  • Very fast response
  • Cable to IEC 60584-1 Class 1
  • Perfect for applications which require a very thin cable
  • 0.08mm dia solid PFA insulated laid flat pair
  • Lead length: 2 metres or 5 metres
  • Operating range: -75ºC to +250ºC
The following types are available:

Ultra Fine Wire PFA Thermocouple (0.08mm dia) without Miniature Plug

Order Code Description 1 - 19 20 - 50 51 - 100 Buy
410-305 Type K - 2 metres $63.00 $57.00 $52.00 Add
410-310 Type K - 5 metres $79.00 $73.00 $66.00 Add
410-315 Type T - 2 metres $63.00 $57.00 $52.00 Add
410-320 Type T - 5 metres $79.00 $73.00 $66.00 Add

Ultra Fine Wire PFA Thermocouple (0.08mm dia) with Miniature Plug

Order Code Description 1 - 19 20 - 50 51 - 100 Buy
410-345 Type K - 2 metres $74.00 $67.00 $61.00 Add
410-350 Type K - 5 metres $90.00 $83.00 $76.00 Add
410-355 Type T - 2 metres $74.00 $67.00 $61.00 Add
410-360 Type T - 5 metres $90.00 $83.00 $76.00 Add
