USB Datalogger - Humidity, Temperature and Dew Point
These data loggers measure and store over 16,000 relative humidity and 16,000 temperature readings over the ranges of 0 to 100%RH and -35 to +80°C (-31 to +176°F). The user can easily set up the logging rate and start-time, and download the stored data by plugging the module straight into a PC's USB port and running the purpose designed software under Windows 7, 8 and 10. Relative humidity, temperature and dew point (the temperature at which water vapour present in the air begins to condense) data can then be graphed, printed and exported to other applications. The data logger is supplied with a long-life lithium battery. Status indication is via flashing red and green LEDs. The logger is protected against ingress from water and dust to IP67 standard when the plastic cap and seal are fitted. Models with or without a high contrast display are available.
- Temperature Range: -35°C to +80°C
- Humidity Range: 0 to 100% RH - Accuracy: ±3.0 (between 20 and 80% RH)
- Dew point indication via Windows Control Software
- User-Programmable Alarm Thresholds for %RH & T
- Supplied with Internal Lithium Battery and Windows Control Software
- Environmental Protection to IP67
- High contrast LCD with two and a half digit display function (357-750)
- Datalogger Set-ups: Logger Name, °C / °F, Logging Rate (10s, 1m, 5m, 30m, 1hr, 6hr, 12hr), High and Low Alarms, Start Date and Start Time
The following types are available:
