Wall Mounted Thermostat for use with NTC sensor
This mains powered wall mounted thermostat is ideal where the fitting of a panel mounted instrument would prove to be difficult. Available either as a single stage or dual stage
thermostat, they are useful in a number of applications such as refrigeration, ovens, heating plants, thermostatic baths and air conditioning. Programming of spans etc. is done from the keypads on the front fascia, which can if necessary be locked out whilst in normal operation. They have a bright easy to read LED indication of the measured value. The thermostat is for use with a NTC thermistor suitable for measuring temperatures from -40ºC to +125ºC.
- Resolution: 0.1°C/1°C/ 0.1°F
- Accuracy ±0.3ºC
- Operating range: -40ºC to +125ºC
- Output: Single or Dual Relay
- Display: 3 digit 14mm high LED
- For use with thermistor probe (10,000 ohms at 25ºC). Choose from 2, 3, 5, or 10
metre long versions of NTC thermistor shown on this page
- Overall size: 90(H)x54(W)x70mm(D)
- Supply voltage: 230V AC
- Mounting: By two screw anchors
The following types are available:
